C35 WD Inspection System Checkweigher for Wet Harsh Environments

C35 WD Inspection System Checkweigher for Wet Harsh Environments

Szczegóły Produktu:
Miejsce pochodzenia: Chiny
Nazwa handlowa: Mettler Toledo
Numer modelu: System Kontroli WD C35
Zapłata:
Minimalne zamówienie: 1 SET
Cena: Zbywalny
Szczegóły pakowania: pudełko karonowe
Czas dostawy: 10-30 dni
Możliwość Supply: 2000 zestawów miesięcznie
Kontakt
Szczegółowy opis produktu
Produkt: System Kontroli WD C35 Przepływ produktu: Przenośnik
Aplikacja kontroli: Kontrola wagi Przemysł: Produkty chemiczne, żywność i napoje, farmaceutyka i biotechnologia
Ważność dokładności: od ±0,1 g MAX WAGI PRODUKTU: 7 kg
Maksymalna prędkość linii: 90 m/min Maksymalna przepustowość: 250 ppm
Łączność: Ethernet TCP/IP FieldBus OPC UA Charakterystyka produktu: Pakiety średniej duże, otwarte, okrągły pojemnik, pakiety małego średnie, mokre
Segment branży: Piwo, wino i inne napoje alkoholowe Typ opakowania: Butelka
Podkreślić:

C35 WD checkweigher for harsh environments

,

Mettler Toledo inspection system

,

wet environment checkweigher inspection system

C35 WD Inspection System Checkweigher for Wet Harsh Environments
Product Overview

The Mettler Toledo C35 WD Inspection System is a high-performance, combination quality control solution specifically engineered to thrive in the most demanding washdown environments. By integrating an advanced checkweigher and a highly sensitive metal detector into a single compact system, the C35 WD delivers comprehensive product inspection and protection in wet and harsh production areas.

Key Features
  • Precision and Versatility: Built for harsh environments to withstand high-pressure cleaning with very high precision at fast speeds
  • Highest Accuracy: MID-certified weighing precision helps comply with regulations and reduces product waste
  • Hygienic Design: Easy access for cleaning with sloped surfaces to prevent liquid retention
  • Resilient Construction: Entire IP69-rated system withstands high-pressure cleaning and caustic detergents
Technical Specifications
Attribute Value
Product Flow Conveyor
Weighing Accuracy from ±0.1 g
Max Product Weight 7 Kg
Max Line Speed 90 m/min
Max Throughput 250 ppm
IP Rating IP69
Max Product Width 400 mm
Weighing Technology EMFR
HMI 15" Touchscreen
Industry Applications

Chemical, Food & Beverage, Pharma & Biotech, including:

  • Beer, Wine and Other Alcoholic Beverages
  • Dairy, Meat & Poultry & Seafood
  • Oils and Fats, Pet Food and Animal Feed
  • Ready Meals, Snack Foods
  • Water and other Non-Alcoholic Beverages
Compatible Packaging Types

Bottle, Bundles, Glass, Trays, Unpackaged

C35 WD Inspection System Checkweigher for Wet Harsh Environments 0
